Lochrin Classic™

Lochrin Classic is a rivetless palisade fence offering quick and simple installation.

Product Details

Lochrin Classic is a rivetless palisade fence where the vertical pales pass through V-shaped slots in the horizontal rails to offer greater protection than a standard front fixed palisade fence.

Due to the pales being rivetless the Classic offers a quick and simple installation solution compared with similar fence types. Available in heights from 0.9m to 4m High the Lochrin® Classic can be fully tailored to your requirements with additional horizontal rails (2, 3 or 4 per panel) or additional pales (Between 17 and 28 per panel).

Best value with lifetime cost! A ‘true’ palisade that conforms to BS1722 part 12 – 2006. Lochrin® Bain rivetless fixing system offers a security palisade fence with tamper-free fixings and pales that pass through the rails with no fixings required.

  • Quick and simple installation.
  • Adaptable using 3mm and 4mm thick pales for strength and reliable security.
  • Heights of 0.90m to 3.6m.
  • Suitable for boundary security, schools, allotments, industrial units, and railways.
  • Full specification drawings, Q40 tender documents and technical support available on request.
  • Post section: 102mm x 44mm RSJ section or 127mm x 76mm universal beams pending specification requirements.
  • 2/3/4 no RSA Horizontal support rails.
  • 45mm x 45mm x 6mm for 3mm pales.
  • 50mm x 50mm x 6mm for 4mm pales.
  • All with V-shaped slots for pale insertion.
  • 3mm or 4mm thick D section pales.
  • 17 no Lochrin pales D Section type to a standard 2.75 metre panel.
  • 2 pressed unique dimples.
  • 2/3/4/ no Fishplate post and rail connectors.
  • 2 no intermediate supports for bottom rail.
  • 6/8/10 no M12 x 30mm cup square fixing bolts.
  • Heights – from 0.90m to 3.6m.
  • Hot Dipped Galvanised to BS EN ISO 1461 or Powder Coated to RAL Colours.
  • Raking panels: 450mm with 17 pales to a standard bay of 2.75 metre panel.
  • Security fencing to BS 1722 part 12.
